·紧凑的外形尺寸，宽光束角;
·色块分BIN优化，颜色均一性好；
·符合LM-80、RoHS等认证；
·通用照明应用的理想LED光源；
| 选择 | 图片 | 产品型号 | Datasheet | Efficacy (lm/W) | CRI(Min.) | Φv(lm) Min.@4000K | Φv(lm) Typ.@4000K | CCT(K) | Current (mA) | Voltage (V) | Power(W) | Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
28TAF-1822R0-xxW909 |
|
164.573820395738 | 90 | 160.0 | 173 | 2700-6500 | 60 | 17.52 | 1 | 18V-1W Series | |
|
28TAF-1822R5-xxW909 |
|
174.509803921569 | 90 | 160.0 | 178 | 2700-6500 | 60 | 17 | 1 | 18V-1W Series | |
|
28TAF-1821N0-xxW909 |
|
120.247568523431 | 90 | 130.0 | 136 | 2700-6500 | 60 | 18.85 | 1 | 18V-1W Series | |
|
28TAF-1821N5-xxW909 |
|
125.73568753344 | 90 | 135.0 | 141 | 2700-6500 | 60 | 18.69 | 1 | 18V-1W Series | |
|
28TAF-1812P0-xxW909 |
|
136.091453456723 | 90 | 140.0 | 150 | 2700-6500 | 60 | 18.37 | 1 | 18V-1W Series | |
|
28TAF-1821Q5-xxW909 |
|
156.774916013438 | 90 | 155.0 | 168 | 2700-6500 | 60 | 17.86 | 1 | 18V-1W Series | |
|
28TAF-1822T5-xxW809 |
|
183.549273655281 | 80 | 175.0 | 187 | 2700-6500 | 60 | 16.98 | 1 | 18V-1W Series | |
|
28TAF-1812R5-xxW809 |
|
152.094717668488 | 80 | 160.0 | 167 | 2700-6500 | 60 | 18.3 | 1 | 18V-1W Series | |
|
28TAF-1821R5-xxW809 |
|
158.204562178072 | 80 | 160.0 | 172 | 2700-6500 | 60 | 18.12 | 1 | 18V-1W Series | |
|
28TAF-1821Q5-xxW809 |
|
143.724334940189 | 80 | 150.0 | 161 | 2700-6500 | 60 | 18.67 | 1 | 18V-1W Series | |
|
28TAF-1822S5-xxW809 |
|
168.944570994685 | 80 | 165.0 | 178 | 2700-6500 | 60 | 17.56 | 1 | 18V-1W Series | |
|
28TAF-1821Q0-xxW809 |
|
136.524822695035 | 80 | 145.0 | 154 | 2700-6500 | 60 | 18.8 | 1 | 18V-1W Series |
